    The more I think about this, the more it makes sense....and then not make sense. I figure a 447/3 that motor wouldn't break a sweat...but it did. However, I did log it (I'm gonna pull my log files this evening because I don't remember the rpm) and it only logged 120a max. 2300kv on 8s would be ridiculous rpm and likely alot more amps than that. I am going to check this again to be sure. It has to be a fluke. ...has to be. My esc would have toasted on 8s and really it should have been faster than it was....unless it just could not turn the prop fast enough....but the amps pulled should be higher....
    32" carbon rivercat single 4s 102mph, 27” mini Rivercat 92mph, kbb34 91mph, jessej micro cat(too fast) was

    Comment

    • kfxguy
      Fast Electric Addict!
      • Oct 2013
      • 8746

      #17
      Originally posted by kfxguy
      The more I think about this, the more it makes sense....and then not make sense. I figure a 447/3 that motor wouldn't break a sweat...but it did. However, I did log it (I'm gonna pull my log files this evening because I don't remember the rpm) and it only logged 120a max. 2300kv on 8s would be ridiculous rpm and likely alot more amps than that. I am going to check this again to be sure. It has to be a fluke. ...has to be. My esc would have toasted on 8s and really it should have been faster than it was....unless it just could not turn the prop fast enough....but the amps pulled should be higher....
      But...the rpm sounds the same between the 2200kv castle that checked in at 2305kv and the 1800kv castle sounds a touch slower. I figure you can hear a 500rpm difference. ..especially a 1000rpm difference. ..
      32" carbon rivercat single 4s 102mph, 27” mini Rivercat 92mph, kbb34 91mph, jessej micro cat(too fast) was

      Comment

      • flraptor07
        Fast Electric Addict!
        • Aug 2013
        • 2451

        #18
        That's really cool Travis, or you can get one of these if you can't or don't want to build one, I've got one and they work great. http://www.hobbypartz.com/26p-motorchecker.html

        Comment

        • gsbuickman
          Fast Electric Addict!
          • Jul 2011
          • 1292

          #19
          Nice Travis, very interesting gadget That would be great to have, especially for matching motors for twin setups. I'd love to see how these speed gems 2 'Platinum' mills I picked up for my Villain X perform :-) . Their rated at 13t x3 & 31,400 rpm, but idk if that's @ 7.2v or 8.4v ?. Since Wake' is back, perhaps he can shed some light on this for us ? :-) . I am planning on running them on 4s with my Astroflight 212D, instead of the hpi gt-550 mills (esavage motors) ...

          Comment

          • kfxguy
            Fast Electric Addict!
            • Oct 2013
            • 8746

            #20
            Originally posted by gsbuickman
            Nice Travis, very interesting gadget That would be great to have, especially for matching motors for twin setups. I'd love to see how these speed gems 2 'Platinum' mills I picked up for my Villain X perform :-) . Their rated at 13t x3 & 31,400 rpm, but idk if that's @ 7.2v or 8.4v ?. Since Wake' is back, perhaps he can shed some light on this for us ? :-) . I am planning on running them on 4s with my Astroflight 212D, instead of the hpi gt-550 mills (esavage motors) ...
            are those motors brushless? I remember running speed gems back in the day.....of course those were brushed....

            flraptor, keith sent me a link to that same unit earlier today. I'm thinking about buying one but i will decide tonight. i'll be doing a bunch more testing to see if this was a fluke or not...
            32" carbon rivercat single 4s 102mph, 27” mini Rivercat 92mph, kbb34 91mph, jessej micro cat(too fast) was

            Comment

            • Fluid
              Fast and Furious
              • Apr 2007
              • 8012

              #21
              ...Just wot is all that matters. I'm not putting a load on it, just want to know my kv, no load.....
              But that is useless information unless all you want to know is if the motor is labeled wrong. The Kv drop under load will actually tell you something useful about how efficient the motor is - and how you can expect it to perform on the water under load. All you need to do is turn the motor around, maybe secure it a bit better, and put an airplane prop on it for a load. It is self-cooling and would produce more useful data. Or not.




              .
              ERROR 403 - This is not the page you are looking for

              Comment

              • kfxguy
                Fast Electric Addict!
                • Oct 2013
                • 8746

                #22
                Originally posted by Fluid
                But that is useless information unless all you want to know is if the motor is labeled wrong. The Kv drop under load will actually tell you something useful about how efficient the motor is - and how you can expect it to perform on the water under load. All you need to do is turn the motor around, maybe secure it a bit better, and put an airplane prop on it for a load. It is self-cooling and would produce more useful data. Or not.




                .
                No, I just simply want to know kv...
                32" carbon rivercat single 4s 102mph, 27” mini Rivercat 92mph, kbb34 91mph, jessej micro cat(too fast) was

                Comment

                • Make-a-Wake
                  FE Rules!
                  • Nov 2009
                  • 5557

                  #23
                  Originally posted by gsbuickman
                  Nice Travis, very interesting gadget That would be great to have, especially for matching motors for twin setups. I'd love to see how these speed gems 2 'Platinum' mills I picked up for my Villain X perform :-) . Their rated at 13t x3 & 31,400 rpm, but idk if that's @ 7.2v or 8.4v ?. Since Wake' is back, perhaps he can shed some light on this for us ? :-) . I am planning on running them on 4s with my Astroflight 212D, instead of the hpi gt-550 mills (esavage motors) ...
                  Hey Jim, hows it goin, Whether its on 7.2 or 8.4v i would not even consider running them on 4s, that would be in the 60,000 rpm range

                  2s max sir.
                  NEED PARALLEL CONNECTORS?? QUALITY 5.5MM, 8MM, 8 AND 10 AWG, GET THEM HERE: http://forums.offshoreelectrics.com/...est!&highlight=

                  Comment

                  • runzwithsizorz
                    Senior Member
                    • Jan 2009
                    • 896

                    #24
                    "2300kv on 8s would be ridiculous rpm". Ummm yeah! even with that 447/3, dogs would have been howling from a mile away. As far as " breaking a sweat ", are you basing that solely on the temp? Cuz, I'm thinking
                    it was the over volting. As far as "alot more amps than 120amps", maybe not, that prop might not have hooked-up. Imagine an unloaded semi tractor rig sitting with it's rear wheels in a pool of oil, running in tenth gear.
                    How much horsepower is it really using?
                    Fluid stated, " if it is really 2300 then you would have burned up your ESC the first time you tried running it in a boat (when assuming it was a 1250 Kv motor) ". Again, maybe not, sometimes we get lucky.
                    kfxguy said it was in a Shocker, and he brought her in with a motor temp. of 130 degrees. but *I* don't know what his ESC was, how long he was out, and what he did with it. I have telemetry with heat probes, and have had to bring a boat back after just 30 seconds, and my equipment survived. A few more seconds, probably not.


                    .
                    Last edited by runzwithsizorz; 10-30-2014, 05:42 PM.

                    Comment

                    • keithbradley
                      Fast Electric Addict!
                      • Jul 2010
                      • 3663

                      #25
                      Originally posted by Fluid
                      But that is useless information unless all you want to know is if the motor is labeled wrong. The Kv drop under load will actually tell you something useful about how efficient the motor is - and how you can expect it to perform on the water under load. All you need to do is turn the motor around, maybe secure it a bit better, and put an airplane prop on it for a load. It is self-cooling and would produce more useful data. Or not.




                      .
                      This is one of the methods we used testing lipos and motors. It's a very simple way to get data regarding performance and efficiency without a lot of variables.
                      www.keithbradleyboats.com

                      Comment

                      • kfxguy
                        Fast Electric Addict!
                        • Oct 2013
                        • 8746

                        #26
                        Originally posted by keithbradley
                        This is one of the methods we used testing lipos and motors. It's a very simple way to get data regarding performance and efficiency without a lot of variables.
                        No doubt that it will, i even have an amp...ugh...logger thing....not sure what youd call it because it doesnt actually log, it just tells you your max amps pulled and current amps being pulled. I'm sure as time goes on, i'll get even deeper into this and do some stuff like that. Mainly what i wanted was a simple tool that i could use to "tweak" my motors. From what i understand, rotor placement has a impact on the motors out put...and with me putting a longer rotor in my 1521 i thought it would be good to find the best placement for it. Also was told by neu that the longer rotor would lower my kv some....I wanted to know by how much.
                        32" carbon rivercat single 4s 102mph, 27” mini Rivercat 92mph, kbb34 91mph, jessej micro cat(too fast) was

                        Comment

                        • kfxguy
                          Fast Electric Addict!
                          • Oct 2013
                          • 8746

                          #27
                          Originally posted by runzwithsizorz
                          "2300kv on 8s would be ridiculous rpm". Ummm yeah! even with that 447/3, dogs would have been howling from a mile away. As far as " breaking a sweat ", are you basing that solely on the temp? Cuz, I'm thinking
                          it was the over volting. As far as "alot more amps than 120amps", maybe not, that prop might not have hooked-up. Imagine an unloaded semi tractor rig sitting with it's rear wheels in a pool of oil, running in tenth gear.
                          How much horsepower is it really using?
                          i just watched some videos of the boat with the 1527 on 6s and 8s. no way its 2300kv. no way. it looks like its in slow motion compared to what im messing with now and the motor does not sound like its turning a bunch of rpm....i'll test some more tonight. maybe i overlooked something this morning...I was leaving for work when I ran out into the shop to test it.
                          32" carbon rivercat single 4s 102mph, 27” mini Rivercat 92mph, kbb34 91mph, jessej micro cat(too fast) was

                          Comment

                          • runzwithsizorz
                            Senior Member
                            • Jan 2009
                            • 896

                            #28
                            Originally posted by kfxguy
                            i just watched some videos of the boat with the 1527 on 6s and 8s. no way its 2300kv. no way. it looks like its in slow motion compared to what im messing with now and the motor does not sound like its turning a bunch of rpm....i'll test some more tonight. maybe i overlooked something this morning...I was leaving for work when I ran out into the shop to test it.
                            Videos of what boat? your Shocker? What ARE you messing with now? Sorry, now I'm confused. a 1527 1y in a Shocker at 8s should not be slow motion. A 1d would be a disaster.

                            Comment

                            • kfxguy
                              Fast Electric Addict!
                              • Oct 2013
                              • 8746

                              #29
                              Originally posted by runzwithsizorz
                              Videos of what boat? your Shocker? What ARE you messing with now? Sorry, now I'm confused. a 1527 1y in a Shocker at 8s should not be slow motion. A 1d would be a disaster.
                              Here's my shocker I had with this exact motor in question. I sold the shocker but bought the motor back from the guy because he put a 1530 in it..... it's not slow....but it looks it when you watch the next video....this is 8s, 447/3 prop



                              32" carbon rivercat single 4s 102mph, 27” mini Rivercat 92mph, kbb34 91mph, jessej micro cat(too fast) was

                              Comment

                              • kfxguy
                                Fast Electric Addict!
                                • Oct 2013
                                • 8746

                                #30
                                This is what I'm messing with right now. Kinda proves that there is no way the 1527 could be 2300kv...

                                Here's my 32" rivercat. Single neu 1521, 1860kv. M645 prop, 7s....

                                You can clearly hear the motor is wound out more...
